    Black Plastic Tote Ibc Tank Container 275 Gallon With Steel Pallet UN Approved

    Ask Lasest Price
    Brand Name : Treering
    Model Number : NL-IBC1000L
    Certification : ISO 9001 ,UN ,food grade inspection report
    Price : Negotiation
    Payment Terms : T/T, L/C, D/A, D/P, Western Union, MoneyGram
    Supply Ability : 50pcs per weeks
    Delivery Time : 3-20 days
    • Product Details
    • Company Profile

    Black Plastic Tote Ibc Tank Container 275 Gallon With Steel Pallet UN Approved

    Plastic Tote Water Tanks 1000 Litre(275 Gallon) New Metal Ibc Container With Steel Pallet - Un Approved

    Description of the 1000L IBC tank

    Changzou Treering Plastics offer 500L 800L , 1000L 1200L IBC Tank,


    which Called Intermediate Bulk Containers (IBC), these tanks meet UN standards for transportation specifications.


    All the tank secured to a galvanized steel pallet, they are easy to maneuver with a forklift or pallet jack.


    Can be stacked two high when full and four high when empty.


    Specification


    The Technical Date of 1000L HDPE IBC tank


    Item


    Specification


    Tolerence


    Rated Volume(L)


    1000L

    None


    Brimful Volume(L)


    <1050L

    None


    Overall Dimension(mm)


    1200*1000*150 mm

    ±2.5%


    Top cap Mouth diameter



    150mm

    ±2 %


    Cap type


    pressure vent and rain cap


    Material of the Inner tank


    otomoulded lower Polyethylene


    Weight for Inner Tank(kg)


    16kg -20 kg

    ±0.5%


    Weight for IBC Tank(kg)


    57-58kg

    ± 2%


    Valve outside diameter(mm)


    50 mm

    ± 1%


    Wall Thickness(min)


    ≥1.5mm


    Outlet Valve(discharge valve)


    DN50 ball valve& butterfly valve


    Height for Pallet(mm)


    120 mm


    Height for forklift holes(mm)


    90 mm


    Material of the cage


    Aluminum or steel galvanized


    Feature
    Made of LLDPE, the inner bottle of the IBC is of Lower density, easy to clean and innocuous.
    More durable and Safety when transport

    Made of first-class hot-dip galvanized steel pipes, the frame of the container is firm, durable and corrosion-resisting.

    Made of engineering plastics, the angle bead and cover plate can well protect the inner barrel and the valve.

    Made of quality galvanized steel plates, the four-way-inlet pallet well protects the inner, and is of best stability, easy to load, unload and stack.

    Equipped with exhaust devices, the container cap ensures liquid safety during transportation.

    Fixed by bolts into the container top, so the inner bottle can be easily replaced.

    IBC Inner Plastic tanks are made of FDA-compliant polyethylene and are protected by a rigid tubular galvanized steel cage.

    Tanks come standard with a 6"(150mm )Vent top opening with threaded cap and TPE gasket, a 2" NPS fill opening, and a drain outlet (Valve) that has a 2" PVC valve and a dust cap. Maximum temperature allowed is 60℃ .The inner tank color is translucent white.

    IBC Tanks are recommended for use in applications where it is critical to ship and store materials in the same container. Can be used for either hazardous or nonhazardous liquids ( Like oil ,ulphuric acid ..) . if you need , the INNER HDPE plastic tank can do UV-blocking additive for extended sunlight exposure resistance.

    The IBC tank Details
    Changzhou Treering IBC tank developing history :
    IBC tank Install detials in the Warehouse :
    The IBC tank have UN certificate , ISO , and food grade inspection report
    Quality Black Plastic Tote Ibc Tank Container 275 Gallon With Steel Pallet UN Approved for sale
